Building RAG Agents with LLMs

A comprehensive hands-on course for building Retrieval-Augmented Generation (RAG) agents using Large Language Models (LLMs). This project combines microservices architecture, LangChain framework, and modern AI technologies to create intelligent conversational agents.

📋 Table of Contents

• Overview
• Features
• Architecture
• Getting Started
  • Prerequisites
  • Installation
  • Quick Start
• Project Structure
• Notebooks Guide
• Microservices
• Running the Application
  • Using Docker Compose
  • Running Individual Services
• Testing
• Configuration
• API Endpoints
• Contributing
• Troubleshooting
• License

🔍 Overview

This project provides a complete learning environment for building RAG (Retrieval-Augmented Generation) agents with Large Language Models. It demonstrates how to:

• Build microservices-based AI applications using Docker and FastAPI
• Implement RAG architectures with vector stores and embeddings
• Create conversational AI agents using LangChain and NVIDIA AI endpoints
• Deploy scalable AI systems with proper orchestration and monitoring

The course is structured as a series of Jupyter notebooks that progressively build knowledge from basic concepts to advanced implementations, culminating in a fully functional RAG chatbot system.

✨ Features

• 🤖 Multiple Chatbot Modes:

  • Basic LLM access without context
  • Context-aware conversations with notebook content
  • Agentic behavior with reasoning capabilities

• 🧠 Advanced RAG Implementation:

  • Document chunking and embedding generation
  • Vector store integration (FAISS)
  • Semantic search and retrieval

• 🌐 Microservices Architecture:

  • Modular, scalable service design
  • Docker containerization
  • API-first approach with FastAPI

• 📚 Educational Content:

  • Progressive learning through Jupyter notebooks
  • Hands-on exercises and examples
  • Visual aids and diagrams

🏗️ Architecture

The project follows a microservices architecture with the following key components:

┌─────────────────┐    ┌─────────────────┐    ┌─────────────────┐
│   Frontend      │    │    Chatbot      │    │   LLM Client    │
│   (Gradio UI)   │◄──►│   (RAG Agent)   │◄──►│  (NVIDIA NIM)   │
└─────────────────┘    └─────────────────┘    └─────────────────┘
         │                       │                       │
         │              ┌─────────────────┐              │
         │              │  Vector Store   │              │
         │              │    (FAISS)      │              │
         │              └─────────────────┘              │
         │                                               │
         └───────────────┐                 ┌─────────────┘
                         │                 │
                    ┌─────────────────┐    │
                    │ Docker Router   │    │
                    │  (Orchestrator) │◄───┘
                    └─────────────────┘

🚀 Getting Started

Prerequisites

• Docker and Docker Compose installed
• Python 3.8+ (for local development)
• NVIDIA API Key (for accessing NVIDIA NIM endpoints)
• Git for cloning the repository

Installation

1. Clone the repository:

   git clone <repository-url>
   cd BuildingRAGAgentswithLLMs

2. Set up environment variables:

   # Copy the example environment file
   copy .env.example .env

   # Edit .env with your actual API keys
   notepad .env

   ⚠️ IMPORTANT: Never commit your .env file! It's already in .gitignore.

3. Build and start the services:

   cd composer
   docker-compose build
   docker-compose up -d

Quick Start

1. Access JupyterLab: Navigate to http://localhost:8888 in your browser
2. Start with the Table of Contents: Open 99_table_of_contents.ipynb
3. Follow the Learning Path: Begin with 00_jupyterlab.ipynb and progress through the numbered notebooks
4. Try the Chatbot: Access the Gradio interface at http://localhost:8999

📁 Project Structure

├── 📓 Notebooks (Learning Materials)
│   ├── 00_jupyterlab.ipynb          # Environment introduction
│   ├── 01_microservices.ipynb       # Microservices concepts
│   ├── 02_llms.ipynb               # Large Language Models
│   ├── 03_langchain_intro.ipynb    # LangChain framework
│   ├── 04_running_state.ipynb      # State management
│   ├── 05_documents.ipynb          # Document processing
│   ├── 06_embeddings.ipynb         # Vector embeddings
│   ├── 07_vectorstores.ipynb       # Vector databases
│   ├── 09_langserve.ipynb          # LangServe deployment
│   └── 99_table_of_contents.ipynb  # Course navigation
│
├── 🤖 Microservices
│   ├── chatbot/                    # RAG chatbot implementation
│   ├── composer/                   # Docker orchestration
│   ├── docker_router/              # Service coordination
│   ├── frontend/                   # User interface
│   └── llm_client/                 # LLM API client
│
├── 📁 Resources
│   ├── imgs/                       # Course images and diagrams
│   └── slides/                     # Presentation materials
│
└── 📄 Configuration Files
    ├── server_app.py               # Main server application
    └── requirements.txt            # Python dependencies

📚 Notebooks Guide

The course is organized as a progressive learning journey:

Notebook	Topic	Description
00	JupyterLab	Environment setup and navigation
01	Microservices	Architecture and containerization
02	LLMs	Large Language Model fundamentals
03	LangChain	Framework introduction and usage
04	Running State	State management in AI applications
05	Documents	Document processing and chunking
06	Embeddings	Vector representations and similarity
07	Vector Stores	Database storage and retrieval
09	LangServe	Production deployment strategies

🔧 Microservices

Chatbot Service

• Location: ./chatbot/
• Purpose: Core RAG agent implementation
• Features: Context-aware conversations, notebook integration
• Port: 8999 (Gradio interface)

Frontend Service

• Location: ./frontend/
• Purpose: User interface and assessment platform
• Port: 8090

LLM Client Service

• Location: ./llm_client/
• Purpose: API gateway to NVIDIA NIM endpoints
• Port: 9000

Docker Router

• Location: ./docker_router/
• Purpose: Service orchestration and monitoring
• Features: Log aggregation, health checks

🏃‍♂️ Running the Application

Using Docker Compose

Start all services:

cd composer
docker-compose up -d

View logs:

docker-compose logs -f [service-name]

Stop services:

docker-compose down

Running Individual Services

Chatbot only:

cd chatbot
pip install -r requirements.txt
python frontend_server.py

LLM Client:

cd llm_client
python client_server.py

🧪 Testing

Interactive Testing

1. Open JupyterLab: http://localhost:8888
2. Run notebook cells: Use Shift+Enter to execute cells
3. Test chatbot: Navigate to http://localhost:8999

API Testing

# Test LLM client endpoint
curl -X POST http://localhost:9000/v1/chat/completions -H "Content-Type: application/json" -d '{"messages": [{"role": "user", "content": "Hello!"}]}'

Service Health Checks

# Check all services status
docker-compose ps

# View service logs
docker-compose logs chatbot

⚙️ Configuration

Environment Variables

# Required
NVIDIA_API_KEY=your_nvidia_api_key

# Optional
NVIDIA_BASE_URL=http://llm_client:9000/v1
NVIDIA_DEFAULT_MODE=open

🔒 API Key Security

For security purposes, all hardcoded API keys have been removed from the notebooks. When you run the notebooks, you'll be prompted to enter your API key securely using getpass() which hides the input.

Two methods to set your API key:

1. Interactive Input (Recommended for learning):

   # The notebooks will prompt you with:
   # Enter your NVIDIA API Key: [hidden input]

2. Environment File (Recommended for development):

   # Create a .env file in the project root
   echo "NVIDIA_API_KEY=your_actual_api_key_here" > .env

   Then in your notebook, load it:

   from dotenv import load_dotenv
   load_dotenv()

⚠️ Security Best Practices:

• Never commit API keys to version control
• Use environment variables or secure vaults in production
• Regularly rotate your API keys
• Limit API key permissions to necessary scopes only

Service Configuration

• Ports: Defined in docker-compose.yml
• Dependencies: Managed through requirements.txt files
• Volumes: Shared storage for notebook content and assessments

🌐 API Endpoints

Chatbot Service (Port 8999)

• GET / - Gradio interface
• POST /chat - Chat completion endpoint

LLM Client (Port 9000)

• POST /v1/chat/completions - OpenAI-compatible endpoint
• GET /health - Health check

Frontend (Port 8090)

• GET / - Assessment interface
• POST /submit - Assessment submission

🤝 Contributing

1. Fork the repository
2. Create a feature branch: git checkout -b feature/amazing-feature
3. Make your changes and test thoroughly
4. Commit your changes: git commit -m 'Add amazing feature'
5. Push to the branch: git push origin feature/amazing-feature
6. Open a Pull Request

🔧 Troubleshooting

Common Issues

Services won't start:

• Check Docker is running: docker --version
• Verify ports aren't in use: netstat -an | findstr :8999
• Check logs: docker-compose logs

Notebook cells fail:

• Ensure all services are running
• Check network connectivity between containers
• Verify API keys are set correctly

API Key Issues:

• Ensure your NVIDIA API key is valid and active
• Check that the key starts with 'nvapi-'
• Verify your API key hasn't expired
• Make sure you have sufficient API quota/credits

Permission errors:

• On Windows, ensure Docker has proper permissions
• Check file sharing settings in Docker Desktop

Memory issues:

• Increase Docker memory allocation
• Monitor resource usage: docker stats

Getting Help

1. Check logs: docker-compose logs [service-name]
2. Restart services: docker-compose restart
3. Rebuild containers: docker-compose build --no-cache
4. Review documentation in the notebooks

📄 License

This project is part of NVIDIA's Deep Learning Institute curriculum. Please refer to NVIDIA DLI terms and conditions for usage rights and restrictions.

---

🎯 Ready to build your first RAG agent? Start with the Table of Contents and begin your journey into the world of AI-powered conversational agents!
